Industrial Lamination Machine




Lamination Machine

Krishna Engineering Works manufactures, exports, and supplies various types of Industrial lamination machine from Ahmedabad, Gujarat, India, such as plastic, paper, LDPE, BOPP, etc.


We have been successfully manufacturing, exporting & supplying all types of Lamination printing machine, Paper Laminating Machine, Thermal Laminating Machine, and Coating Machine since last 25 years from Ahmedabad, Gujarat, India. We have won 3 times national awards and 2 times international awards for industrial products. For the lamination machine, we have processed all kinds of materials like polyester, BOPP, LD, PVC, paper, film, etc. We have more than 100 installations of lamination machines in India and abroad such as in Saudi Arabia, UAE, and Dubai. Sharjah and the South. Africa, Nigeria, Ghana, Congo, Kenya, Zambia, Sri Lanka, Bangladesh, Malaysia, Nepal, Russia, Thailand, Indonesia, Brazil, Colombia, Venezuela, Argentina, Mexico, Canada, etc..


   Lamination Machine Video


Lamination Printing Machine

The Principle

The film laminating machine uses polyester (PET) film as its base film, and adhesive (EVA resin) is applied evenly on one side of the polyester (PET) film. After special processing, it was transformed into advanced packing material, and it is widely used for laminating and protecting materials such as identity cards, historical accounts, photos, pictures, credit cards, and important documents. After laminating, the material has unique functions such as water resistance, change resistance, wet resistance, worm resistance, and mildew resistance on a normal acid-base. In addition, it is hard, smooth, and pleasing to the eye of the person, as it has good transparency.


The Use Of Automatic Lamination Machine:

Our industrial lamination machine is used to laminate all kinds of materials. The laminated machine is widely used for plastic and paper materials like milk pouches, wafer pouches, food packets, cloth bags, etc.


KEW offers a high-speed industrial laminating machine with high precision and organized operation. This machine is easy to handle, install and operate, it can be used easily.


Type of High Speed Laminating Machine:
  • Sheet laminating machine
  • Dry laminating machine
  • Wet laminating machine
  • Heat laminating machine
  • Roll Laminating Machine

Salient Features:
  • Heavy-duty C.I. Cast iron and heavy forged structure.
  • Gravure type coating system.
  • Cantilever type imprint pressure for aerated pistons with rubber roll doctor blades and nip rollers.
  • Fully insulated imported special glass wool sheet fitted to the panel (top and bottom) to control heat loss.
  • One and one slit-type counter airflow configuration for proper web support, split evenly in front of the roller.
  • Exhaust is distributed in lengths of drawing chamber and individual exhaust ducts for each zone.
  • Digital temperature controller with zone indicator and PT 100 sensor.
  • Inside heating for Nip Steel roller.
  • Types of heavy-duty shafts fix the rewinder with the motor.
  • KEW SRA Web system two webs to control the web after drying and for primary and secondary comfort.

Example of Coating Methods
  • Reverse roll coating with nip feed
  • Top nip fed three-roll reverse roll coater
  • Gravure reverse roll coater
  • Gravure roll coating with an oscillating doctor blade
  • Five rolls (smooth) coating
  • Kiss coating with an air knife
  • Kiss coating with Mayer bar

Technical Specifications:
  • Web Width : 400 – 2400mm
  • Unwind Rewind Diameter : 600 - 1000mm
  • Hot Air Temp : 250°C / 50 – 150
  • Machine Speed : 60 – 200 M/Min.
  • Heat Source : Hot Air Generator (Optional)
  • Exhaust : 5 HP
  • Synchronized Drive : 5 HP/5 / 7.5,10 / 3 HP for Coater, Nip, Rewind & Positive Drive (Optional)
  • Material to be Laminated : Polyester/Paper/Poly/BOPP/Aluminum Foil/HDPE Fabrics etc.

Unwind Station:
  • Stress control brake unit with electrical/pneumatic (load cell feedback).
  • Relaxable with a web guide.

Coating Unit:
  • Independent A.C. Drive.
  • Pre – Heating / Exhaust.

Drying Chamber:
  • Load cell feedback for coating & Nip.
  • Top door aerated training.
  • Cat walk for full length drying chamber.
  • Programmable Temperature Control.
  • Positive tunnel drive.

Hot Air Generator:
  • Coal or wood-fired air heater/diesel / thermal fluid heater with blower.

Dry Laminating Unit:
  • Web Chaser

Rewind Station:
  • A. C. synchronize Drive with Load cell.
  • Center winding system / Surface.

Optional Attachment:
  • Air Shaft
  • Bridge roll assembly in feed drive
  • Reverse Roll / May bar, air knife three roll.
  • Arrangement of wet lamination.
  • Exhaust individual and additional blower for each zone.
  • Chill Roll.
  • Bow Roller.
  • Ink Circulating with Viscosity Control.
  • Touch Screen Operated control for all drive.
